ALUMATE® Aluminium Shiplap Cladding

ALUMATE Aluminium architectural facade system enhances the look and feel of any outdoor façade, soffit and internal wall & ceiling linings. ALUMATE is Ideal for any new buildings or renovations and is suitable for both residential and commercial applications where low maintenance, durable, non-combustible realistic wood grain finish is required.

ALUMATE Aluminium facade product comes in varying widths and offers straight forward fixing methods making it highly flexible for any design specification and application. Featuring an interlocking tongue and groove design to achieve concealed fixings while providing a conventional timber appearance with a clean and durable finish, ALUMATE Aluminium cladding can be orientated either vertically or horizontally in order to deliver a clean finish with consistently spaced shadow / join lines.

Alumate materials consist primarily of lightweight aluminium, including aluminium extrusions and panels which utilise a range of unique kits and modular components providing designers the flexibility to create truly exceptional looks.

Alumate aluminium cladding can be used on the exterior facades or soffits of projects and is also suitable for interior ceilings and internal lining. Alumate aluminium cladding can be integrated into interior or exterior architectural designs. Alumate aluminium cladding products are available in a variety of high-quality finishes, including realistic wood grains and marble, as well as solid colour powder coating and anodising to suit nearly any design intent while remaining easy to install, durable, with the added benefit of low maintenance.

Alumate aluminium cladding is ideal for any new build or refurbishment, making it suitable for residential and commercial applications where low maintenance and durability are desired.

Alumate aluminium cladding utilises several systems including: Alumate shiplap cladding systems, Alumate cassette panel cladding systems and click-on Alumate cladding systems.

Alumate Aluminium façade systems are available in different widths and lengths while offering simple fixing methods which makes them highly flexible and adaptable to any design specification and application. Alumate aluminium cladding systems can be orientated vertically or horizontally to provide a clean finish and consistently spaced shadow/joining lines.

Alumate aluminium cladding products are tested to comply with the Australian Fire Protection Standard AS 1530.1.

Advantages

  • Non-Combustible
  • Low maintenance
  • Durable
  • Easy installation with Pre-slotted fixing points
  • All sizes of cladding profiles interlock with each other
  • Profile Coverage(1):165mm
    Visual Board Coverage: 83mm or 165mm
  • Profile Coverage(2):150mm
    Visual Board Coverage: 150mm
  • Wide range of realistic wood grain finishes
  • Vertical and horizontal installation options
  • Full suite of accessories in matching profile colours

Specifications

  • Grade 6063-T5 Aluminium extrusion profiles and accessories
  • Decoral Aluminium heat transfer surface finishing
  • Certified AS 1530.1-1994 Compliant – Non-Combustible
  • Density 2712 kg/m³
  • Ultimate Tensile Strength 140 MPa
  • Yield Strength 97 MPa
  • Young’s Modulus 69 GPa
  • Melting Temperature 615°C
  • Thermal Conductivity 201-218 W/m°K
